In industries such as oil drilling, mining, and tunnel construction, mud cooling systems are crucial equipment for

ensuring the stable operation of devices and enhancing operational efficiency. However, the cooling requirements

for mud under different working conditions vary greatly. How to choose an appropriate cooling solution?

When communicating with clients, it is essential to confirm the following seven key issues to ensure that the system

design precisely matches the actual needs.

1. Mud properties: water-based, oil-based or other media?

The type of mud directly affects the material selection of the cooling system and the heat exchange method:

Water-based slurry: Common, with relatively low corrosiveness, and is generally used in conventional heat exchangers.

Oil-based mud: It has a relatively high viscosity and requires consideration of explosion-proof and special heat exchange structures.

Other media: such as synthetic base mud, need to be designed specifically.

2. Mud treatment capacity (m³/h)

The processing capacity of the mud cooling system must match the mud flow rate. If it is too small, it will lead to insufficient cooling; if it is too large, it will increase the cost.

3. Cooling range requirement: Initial temperature vs. target temperature

Initial temperature: The temperature of the mud before it enters the cooling system (such as after the solid control system).

Target temperature: The temperature that needs to be achieved after cooling.

For instance, if the initial temperature is 60℃ and it is required to be reduced to 40℃, then the cooling range is 20℃.

4. Solid content and density of the mud

Solid content (%) : It affects the fluidity and heat exchange efficiency of the slurry. High solid content may require the addition of anti-clogging design.

Density (g/cm³) : Affects pumping power and heat exchange calculation.

5. Type and temperature of cold source

Most mud cooling systems use water as the cold source, but different water sources have a significant impact on the equipment:

Tap water: Clean, not prone to scaling, recommended for use.

Well water/lake water/seawater: May contain impurities and requires anti-scaling and anti-corrosion design.

Cold source temperature: It directly affects the heat exchange efficiency and requires precise measurement.

6. Equipment installation environment

Environmental temperature and humidity (especially wet bulb temperature) have a significant impact on the cooling effect. It should be clear that:

Installation locations: indoor, outdoor, offshore platforms, deserts, etc.

Extreme weather conditions: Special protection is required in high-temperature, high-humidity and high-salt fog environments.

7. Customized technical solutions

Based on the above parameters, the technical team of Xi 'an KOSUN can calculate the heat load, select the appropriate heat exchanger (such as air-cooled form,
water-cooled form, or a combination of air-cooled and water-cooled form, etc.), and provide customized designs such as anti-scaling, anti-corrosion, and explosion-proof.
